PL14WJ-09-08

Vifa 5½" midwoofer coated paper cone NR rubber surround
PL14WJ-09-08
With shipment TNT track&trace for 7,75 €
Sales price 88,46 €
Sales price without tax 73,11 €
Discount
Tax amount 15,35 €
Description
Electrical Data
Nominal Impedance Zn 8 ohm
Maximum Impedance Zo 32 ohm
DC Resistance Re 5.8 ohm
Voice Coil Inductance Le 0.49 mH
TS Parameters
Resonance Frequency fs 47 Hz
Mechanical Q factor QMS 2.2
Electrical Q factor QES 0.46
Total Q factor Qts 0.38
Force Factor Bl 5.5 Tm
Mechanical Resistance Rms 1.3 Kg/s
Moving Mass Mms 8.2 g
Effective Piston Area sd 80 cm^2
Equivalent Volume Vas 13 ltrs
Sensitivity 2.83V/1m 86 dB
Power Handling
Long-term Max Power IEC 18.3 200 W
Short Term Max power IEC 18.2 250 ohm
Voice Coil and Magnet Parameters
Voice Coil Diameter 32 mm
Voice Coil Height 10 mm
Height of the Gap 4 mm
Weight of Magnet 0.415 Kg



Exclusive shipping.

Units in box: 65537
